Features
Equipped with Honda GP200
▶ High Power (4.2Kw)
▶ Easy start
▶ High idling stability
▶ Low vibration, Low noise
▶ Low fuel consumption
Reliability/Durability
▶ Proven GP200 durability
▶ Mud-water resistant recoil starter
Safety
▶ Large-size Sub-fender
▶ OPC System
▶ Birdcage Muffler Guard
Easy Operation/User Friendly
▶ Light weight (55kg)
▶ Height adjustable handlebar (3 Level)
▶ Rotor Holder
▶ Transportation Wheel (Rubber)
Features
-
Operator Presence Control System
-
Birdcage Muffler Guard
-
Transportation Wheel
-
Front Stand
-
Gear Shifting Gate
-
Large-size Sub-fender
-
Engine guard and Rotor Holder
-
Handlebar Height Adjustment
Specifications
|
Dimesions |
Specifications |
|
Overall Length (mm) |
1475.0 |
|
Overall Width |
650.0 |
|
Overall Height |
1000 |
|
Dry Mass (kg) +Oil+Rotor Dry Mass+Tire,Fuel not included |
61.6 65.2 |
|
Engine Name |
GP200H |
|
Total Displacement (cm3) |
196.0 |
|
Valve system, Cooling, Cycle, Cylinder |
OHV Air-cooled 4-st. Single-cylinder |
|
Engine Net Power [ kW/rpm ] |
4.3 / 3600 |
|
Continuous Rated Power [ kW/rpm ] |
3.7 / 3600 |
|
Engine Max. Net Torque [ N･m(kg･m)/rpm ] |
12.4 / 2500 |
|
Idling Speed (rpm) |
1400 (+200, -150) |
|
Max. Idling Speed (rpm) |
3800 (+0, -200) |
|
Starter System |
Recoil starter |
|
Recoil starter cover |
Mud-water resistant type |
|
Air Cleaner System |
Dual type |
|
Air intake |
Air Cleaner |
|
Carburetor drain |
Carburetor Body |
|
Fuel tank capacity (L) |
2.4 |
|
Clutch Type |
Belt tension type |
|
Operation Method |
Manual Lever |
|
No. of Gears |
Forward 2 / Reverse 1 |
|
Axle Rotating Speed (rpm) |
1st. 91.4/ 2nd. 119.9 / R 65.4 |
|
Tillage Width (mm) |
900.0 |
|
Rotor ASSY |
Φ300 |
|
Height Adjustable |
3 shifts adjustable |
|
Shape |
Y Shape |
|
Fender |
Main + Large-size Sub-Fender |
|
Transportation Wheel Diameter |
Φ260 |
